| 브랜드 이름: | TIANMA |
| 모델 번호: | TM101DDHG01 |
| MOQ: | 10PCS |
| 가격: | negotiable |
| 지불 조건: | T/T,W,웨스턴 유니온,MoneyGram |
| 공급 능력: | 주당 3000pc |
| Manufacturer | Chimei Innolux |
| Model Name | N101LGE-L11 |
| Display Size | 10.1" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1024(RGB)×600, WSVGA, 16:9 |
| Dot Layout | RGB Vertical Stripe |
| Display Area | 222.72(W)×125.28(H) mm |
| Panel Weight | 180/190g (Typ./Max.) |
| Outline Size | 235(W)×143(H)×5.2(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 200 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 45/45/20/45 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| View Direction | 6 o'clock |
| Response Time | 3/7 (Typ.)(Tr/Td) ms |
| Display Colors | 262K, 45% NTSC |
| Touch Screen | Without |
| Shape Style | Wedge (PCBA Bent, T≥5.2mm) |
| Light Source | WLED, 15K hrs, With LED Driver |
| Frequency | 60Hz |
| Application | Tablet PC |
| Interface | LVDS (1 ch, 6-bit), 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -20 ~ 60 °C |
