| 브랜드 이름: | BOE |
| 모델 번호: | av101hdm-n10-28p2 |
| MOQ: | 10PCS |
| 가격: | negotiable |
| 지불 조건: | T/T,W,웨스턴 유니온,MoneyGram |
| 공급 능력: | 주당 3000pc |
| Model Number | AV101HDM-N10-28P2 |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1280(RGB)*720 (WXGA), 145 PPI |
| Active Area | 223.68*125.82 mm |
| Brightness | 1000 cd/m² (Typical) |
| Contrast Ratio | 1000:1 (Typical) |
| Viewing Angle | 85/85/85/85 (CR≥10) |
| Response Time | 30 ms maximum (Tr+Td) |
| Interface | LVDS (1 channel, 8-bit), 60-pin connector |
| Power Supply | 3.3V typical |
| Operating Temperature | -30°C to 85°C |
| Storage Temperature | -40°C to 90°C |
| Touch Panel | Without touch screen |
