LG 27Inch Desktop LCD Display Panel LW270AHQ-ERG2 2560x1440Pixels FHD 110PPI lcd tablet 112pin

LG 27Inch Desktop LCD Display Panel LW270AHQ-ERG2 2560x1440Pixels FHD 110PPI lcd tablet 112pin

브랜드 이름: BOE
모델 번호: LW270AHQ-ERG2
MOQ: 10pcs
가격: negotiable
포장에 대한 세부 사항: 산업 포장
지불 조건: T/T, W, Western Union, MoneyGram
자세한 정보
원래 장소:
중국
인증:
Rohs,CE,FCC
품질:
새로운 원본
패키지:
오리지널 산업 포장
해결:
2560*1440픽셀
스타일:
112핀 IPS
명도:
150CD/M2
색상:
1.07B
대비 비율:
1500 : 1
일하는 삶:
30k 시간
화면 크기:
27 인치
터치 스크린:
없이
공급 능력:
주당 3000pc
제품 설명

LG 27Inch Desktop LCD Display Panel LW270AHQ-ERG2 2560x1440Pixels FHD 110PPI lcd tablet 112pin



The LW270AHQ-ERG2 (Alias: LW270AHQ (ER)(G2)) is a 27.0 inch diagonal AM-OLED display panel product from LG Display Co., Ltd. (hereafter called LG Display), it self emiting, without touch screen. It features an operating temperature range of 0 ~ 45°C , a storage temperature range of -20 ~ 60°C . It's general features are summarized by Einklcd in the following: DCI-P3, sRGB, HDR600, 240Hz, 10 bit, Matte , HDR800 10%, HDR1000 3.0%. Based on its features, einklcd recommend that this model be applied to Desktop Monitor, Gaming etc. According to the information stored in einklcd this model mass production on Q3, 2022, Now this model is in production.  We inputted this model's specification on Apr 7 2023 for the first time, and the latest update on Sep 16 2025. If you want to embed LW270AHQ-ERG2 OLED in your future product, Einklcd strongly recommend that you should contact with LG Display or it's agent to learn lateast production and specification detail. The LW270AHQ-ERG2 production status marked on einklcd.com is for reference only and should not be used as the basis for the user's decision making.





Brand LG
Display Model P/N: LW270AHQ-ERG2
Diagonal Size 27.0"
Panel Type: AM-OLED, OLED , Full Module
Resolution 2560(RWGB)×1440, Quad-HD 110PPI
Pixel Format: RGBW Vertical Stripe
Active Area 590.42(W)×333.72(H) mm
Bezel Opening-
Outline Dim. 604.42(H)×350.62(V) mm
Treatment Antiglare (Haze 35%), Reflection 2.0% (Typ.)
Luminance 150 cd/m² (Typ.)
Contrast Ratio 1500000:1 (Typ.) (TM)
View Direction Symmetry Response Time 0.1 (Typ.)(G to G)
Viewing Angle 60/60/60/60 Left / Right / Up / Down Operating Mode -
Support Color 1.07B 98% DCI-P3
Light Source self , 30K hours
Weight 3.20/3.4Kgs (Typ./Max.)
Designed For:Desktop Monitor Gaming
Frame Rate 240Hz
120Hz (60HZ Input) : Embedded MEMC Circuit
120Hz+120Hz : 120Hz Panel+120Hz Backlight
240Hz (60HZ Input) : Embedded MEMC Circuit
Touch Panel:Without
Interface Type V-by-One 16 lane , 112 pins Connector
Power Supply 12/19.5V (Typ.)(VDD/ELVDD)
Environment Operating Temperature: 0 ~ 45 °C ;
Storage Temperature: -20 ~ 60 °C

LG 27Inch Desktop  LCD Display Panel LW270AHQ-ERG2 2560x1440Pixels FHD 110PPI lcd tablet 112pin 0
LG 27Inch Desktop  LCD Display Panel LW270AHQ-ERG2 2560x1440Pixels FHD 110PPI lcd tablet 112pin 1
